Radiographic Testing (RT) is a powerful non-destructive testing (NDT) method like Visual Testing (VT) or Ultrasonic Testing (UT) used to detect internal defects in materials and welded structures. By utilizing X-rays or gamma rays, RT provides a clear view of subsurface discontinuities, making it an essential tool in industries such as oil & gas, aerospace, power generation, and manufacturing.
In this guide, we will cover:
✔ What is Radiographic Testing (RT)?
✔ Types of radiation sources used in RT
✔ Step-by-step process of RT inspection
✔ How to interpret radiographic images
✔ Advantages and limitations of RT
Let’s explore how industrial radiography ensures the safety and reliability of critical components!
What is Radiographic Testing (RT)?
Radiographic Testing (RT) is an NDT method that uses high-energy radiation (X-rays or gamma rays) to inspect the internal structure of materials. The radiation penetrates the test object, and variations in thickness or density create a shadow image on film or a digital detector.
✔ Purpose: Detect cracks, voids, inclusions, lack of fusion, and other internal defects.
✔ Applicable Materials: Metals, composites, ceramics, and some polymers.
✔ Common Applications: Welding inspection, pipeline integrity testing, pressure vessel inspection, aerospace, and casting evaluation.
📌 Note: At NWE, we specialize in inspection and supervision for RT procedures, ensuring compliance, accuracy, and safety—but we do not perform the RT testing directly.
Types of Radiation Sources in Radiographic Testing (RT)
In RT, radiation sources are divided into two main categories:
1️⃣ Radioactive Isotopes (Gamma Ray Sources)
Certain isotopes emit gamma rays, which can be used for industrial radiography without electricity.
✔ Common Isotopes Used:
- Iridium-192 (Ir-192): Ideal for medium-thickness steel components.
- Cobalt-60 (Co-60): Suitable for thick sections due to its high energy.
- Cesium-137 (Cs-137): Used for inspecting low-density materials.
✔ Advantages:
✅ Highly portable and effective for on-site inspections.
✅ Can penetrate thicker materials compared to X-rays.
✔ Limitations:
❌ Requires strict radiation safety controls due to prolonged exposure risks.
❌ Lower image resolution compared to X-ray sources.
2️⃣ X-Ray Generators (Artificial X-Ray Sources)
X-ray machines use electric power to generate high-energy radiation for industrial radiography.
✔ Types of X-Ray Generators:
- Low-energy X-ray tubes – Suitable for thin materials and electronics.
- High-energy X-ray machines – Used for thick metals and heavy industrial components.
- Linear accelerators (LINACs) – Advanced systems for high-precision radiography in critical applications.
✔ Advantages:
✅ Produces high-resolution images with excellent defect detection capability.
✅ No need for handling radioactive materials, making it safer than gamma sources.
✔ Limitations:
❌ Requires power supply, making it less portable.
❌ Limited penetration compared to Cobalt-60 gamma rays.
How Industrial Radiographic Testing (RT) is Performed
The RT inspection process follows a systematic approach to ensure accurate and high-quality imaging.
🔹 Step 1: Preparing the Test Object
✔ Ensure the surface is clean to avoid image distortion.
✔ Position the component correctly for optimal defect detection.
🔹 Step 2: Selecting the Radiation Source
✔ Choose X-ray or gamma rays based on material thickness and inspection requirements.
✔ Adjust energy levels for the best image contrast and resolution.
🔹 Step 3: Placing the Detector (Film or Digital Sensor)
✔ Traditional X-ray film or modern digital imaging sensors capture the radiographic image.
✔ Film-based RT requires chemical processing, while digital RT provides instant results.
🔹 Step 4: Exposing the Object to Radiation
✔ The radiation source is activated, allowing X-rays or gamma rays to penetrate the material.
✔ Defects and material variations create density differences on the detector.
🔹 Step 5: Image Processing & Interpretation
✔ The radiographic image is analyzed for discontinuities, cracks, voids, or weld defects.
✔ Inspectors use reference charts to classify defect severity.
How to Interpret Radiographic Images?
Radiographic images reveal internal defects based on contrast and density variations.
✔ Dark Areas: Indicate low-density defects like porosity, cracks, or inclusions.
✔ Light Areas: Represent denser material sections with no significant flaws.
✔ Sharp, Well-Defined Defects: Usually indicate cracks or incomplete fusion.
✔ Blurry, Gradual Variations: Suggest thickness variations or inclusions.
🔎 Example Applications:
✔ Pipeline inspection: Detecting corrosion, lack of penetration, and wall thinning.
✔ Aerospace components: Ensuring turbine blades and aircraft structures are defect-free.
✔ Weld integrity testing: Identifying internal weld discontinuities.
Advantages & Limitations of Radiographic Testing (RT)
Like any NDT method, RT has both benefits and limitations depending on the inspection requirements.
✅ Advantages of Radiographic Testing (RT)
✔ Detects internal defects that are invisible to surface inspections.
✔ Suitable for a wide range of materials (metals, composites, ceramics).
✔ Permanent records – RT images can be stored for future analysis.
✔ Provides high-resolution imaging for precise defect evaluation.
✔ Compatible with automated digital radiography (DR) and computed radiography (CR) for real-time analysis.
❌ Limitations of Radiographic Testing (RT)
❌ Radiation hazards – Requires strict safety regulations and shielding.
❌ High costs – X-ray machines and isotope handling require significant investment.
❌ Time-consuming – Film development and setup can slow down the process.
❌ Not suitable for very thick materials unless using high-energy sources like Cobalt-60 or LINAC.
Radiographic Testing (RT) Inspection Checklist ✅
A structured RT checklist ensures a thorough, accurate, and compliant inspection process. Below is a practical Radiographic Testing (RT) checklist covering key aspects of preparation, execution, and evaluation in industrial radiography.
1️⃣ Pre-Inspection Checklist
| Inspection Step | Check (✔/✖) |
| Verify Inspection Plan – Ensure compliance with industry standards (ASME, ASTM, ISO, etc.) | |
| Confirm Radiation Safety Measures | |
| 🔹 Proper shielding and controlled exposure zones | |
| 🔹 Radiation warning signs and PPE for workers | |
| Select Radiation Source – Choose X-ray or gamma-ray based on material thickness | |
| Check Equipment Calibration – Ensure X-ray machines or isotope sources are properly calibrated | |
| Surface Preparation – Clean surfaces to remove dirt, paint, or scale that could distort results | |
| Film or Digital Detector Selection – Choose the right imaging method (film-based or digital RT) |
2️⃣ RT Execution Checklist
| Inspection Step | Check (✔/✖) |
| Proper Placement of Radiation Source & Detector | |
| 🔹 Ensure correct source-to-object distance (SOD) | |
| 🔹 Align the film or digital detector for clear image capture | |
| Set Correct Exposure Time & Energy Levels – Adjust settings for optimal contrast and resolution | |
| Monitor Environmental Conditions | |
| 🔹 Avoid temperature, humidity, or vibrations affecting imaging quality | |
| Ensure Controlled Radiation Exposure – Follow dose limits & shielding to minimize radiation risks | |
| Verify Image Quality Before Proceeding | |
| 🔹 Check for blurriness, underexposure, or overexposure | |
| 🔹 Use IQI (Image Quality Indicator) to validate image accuracy |
3️⃣ Post-Inspection & Evaluation Checklist
| Inspection Step | Check (✔/✖) |
| Analyze Radiographic Images for Defects | |
| 🔹 Identify cracks, porosity, lack of fusion, slag inclusions, etc. | |
| Compare Findings with Acceptance Criteria | |
| 🔹 Evaluate results using industry codes (ASME, AWS, ISO, etc.) | |
| Record & Store Inspection Data | |
| 🔹 Maintain film/digital records for traceability | |
| Prepare a Detailed RT Inspection Report | |
| 🔹 Include findings, defect locations, image analysis, and recommendations | |
| Ensure Proper Disposal of Used Film/Chemicals (if applicable) |
4️⃣ Final Review & Compliance Check
| Inspection Step | Check (✔/✖) |
| Verify that all safety protocols were followed | |
| Confirm results meet regulatory requirements | |
| Ensure recommendations for repairs or further testing are documented |
Why Use This RT Checklist?
✅ Ensures compliance with ASME, ASTM, ISO, and AWS standards.
✅ Improves inspection accuracy by covering all key steps.
✅ Enhances defect detection for reliable decision-making.
✅ Provides structured documentation for traceability.
Need Expert Supervision for RT Inspections?
At NWE, we provide specialized RT inspection oversight, ensuring compliance, accuracy, and safety in industrial radiographic testing.
✅ Get in touch with our experts today!
📌 Related Services & Applications
✔ Welding Inspection – Ensuring weld integrity and defect-free joints.
✔ Pipeline Inspection – Detecting corrosion, cracks, and wall thinning.
✔ Pressure Vessel Inspection – Evaluating the safety of high-pressure systems.
People Also Ask (FAQ)
🔹 What defects can be detected using Radiographic Testing (RT)?
✔ RT detects cracks, voids, porosity, inclusions, lack of fusion, and thickness variations.
🔹 What is the difference between X-ray and gamma-ray RT?
✔ X-ray RT provides higher image resolution but has limited penetration.
✔ Gamma-ray RT can inspect thicker materials but requires radioactive sources.
🔹 Is RT safe for on-site industrial applications?
✔ Yes, but strict radiation safety protocols must be followed. Lead shielding, controlled exposure times, and trained personnel are required.
🔹 Which industries use RT the most?
✔ Oil & Gas, Aerospace, Automotive, Power Plants, Pressure Vessel Manufacturing, and Heavy Equipment Production.
Conclusion: Why Radiographic Testing (RT) is Essential for Industrial Inspections
Radiographic Testing (RT) is crucial for detecting internal flaws in components through high-resolution X-ray or gamma-ray imaging. NWE offers expert third-party NDT supervision for RT inspections, ensuring:
-
Thorough review of RT procedures for accuracy and safety
-
Verification of image quality for proper defect detection
-
Expert recommendations for corrective actions
Need professional RT inspection supervision?
Contact NWE for precise, safe, and compliant inspections today!
